CPU: AMD Socket FM2+ Athlon™/A- Series Processors
Supports CPU up to 4 cores
Supports AMD® Turbo Core 3.0 Technology
Chipset AMD A68H FCH (Bolton D2H)
Memoria
2 x DIMM, Max. 32GB
DDR3 2400(O.C.)/2133/1866/1600/1333 MHZ
Gráficos:
Integrated AMD Radeon™ R/HD8000/HD7000 Series Graphics in the A-Series APU
Multi-VGA output support : HDMI/DVI/RGB ports
Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 1920 x 1200 @ 60 Hz
Supports DVI with max. resolution 2560 x 1600 @ 60 Hz
Supports RGB with max. resolution 1920 x 1600 @ 60 Hz
Maximum shared memory of 2048 MB
AMD® Dual Graphics technology support *1
Ranuras de expansión
1 x PCIe 3.0/2.0 x16 *2
1 x PCIe 2.0 x1
1 x PCI
Lan
Realtek® 8111GR, 1 x Gigabit LAN Controller(s)
Audio
Realtek® ALC887-VD 8-Channel High Definition Audio CODEC *3
Puertos USB
ASMedia® ASM1042 controller :
2 x USB 3.1 Gen 1 port(s) (2 at back panel, blue)
AMD A68H FCH (Bolton D2H) chipset :
6 x USB 2.0/1.1 port(s) (2 at back panel, , 4 at mid-board)
AMD A68H FCH (Bolton D2H) chipset :
2 x USB 3.1 Gen 1 port(s) (2 at mid-board)
E/S panel trasero  1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
1 x DVI
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.1 Gen 1
2 x USB 2.0
3 x Audio jack(s)
Sistema Operativo
Windows 7 , 32bit/64bit
Windows® 8.1 , 32bit/64bit
Windows® 8 , 32bit/64bit
Windows® XP 32bit
Formato de fábrica:
mATX Form Factor ( 22.6 cm x 18.3 cm )
